4T8M Electric Knuckle Telescopic Pedestal Mounted Fish Ship Crane
Knuckle Marine Crane Features
1.Self contained unit with integrated hydraulic power pack.
2.Fail-safe brakes on all movements.
3.Fully enclosed and equipped drivers cabin with integrated heating.
4.Dual pump system with separate hydraulic circuit for hoist and luffing/slewing to ensure efficient cargo handling.
5. The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.
6. Base on many year's experience of crane and harbor equipment.
7. All components are imported from Europe and USA and reach a global service agreement.
8. Suitable for all kinds of ships and low power consumption and high efficiency.
Product Feature
1.Easy maintenance at all situation.
2.Self contained unit with integrated hydraulic power pack.
3.Fail-safe brakes on all movements.
4.Fully enclosed and equipped operator cabin with air condition.
5.The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.
6.Technology from Germany.
7.Base on many year's design and fabrication experience of crane and other similar equipment.
8.Suitable for all kinds of ships and low power consumption and high efficiency.
9.Welded and high strength box boom for easy maintenance.
10.With Many safety protection devices---hook up limiter and overload limiter, emergency stop button.
TECHNICAL SPECIFICATION
1. SWL 4t
2. MAX. WORKING RADIUS 8m
3. MIN. WORKING RADIUS 2m
4. HOISTING SPEED 0～12m/min
5. HOISTING HEIGHT 15m
6. SLEWING SPEED ～0.6r/min
7. SLEWING ANGLE 360°
8. LUFFING TIME ～60S
9. WORKING CONDITION
TRIM ≤2°
HEEL ≤5°
10. DESIGN TEMPERATURE -10°～+45°
11. HPU 37KW
12. LUFFING ANGLE 0-75°
13. POWER RESOURCE 380V/50HZ
14. DEAD WEIGHT 4000kg
4T8M Marine Crane Drawing
Product Details
Packing & Shipping
Our company provides professional packaging and transportation for the products.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
| Packing | Nude |
| Delivery | Standard product : 1month Customized product: 2 months Certified products: 3-4 months |
Workshop
Our company has modern production factory and experienced production workers.Modern operation technology and strict supervision system guarantee the quality of products.
Once Cooperation Be Friends Forever
Our company participates in various exhibitions every year and presents our products to partners and customers around the world.
We have our own factory and welcome friends from all over the world to visit us.Once Cooperation Be Friends Forever.
FAQ
1.Q: What's the working radius of your crane?
A: From 1m to 100m, we can also design and manufacture cranes according to your requirements.
2. Q: Which crane type should I choose?
A: We have foldable boom, knuckle boom, telescopic boom, stiff boom, etc.
3. Q: Is this crane explosion-proof?
A: Sure, we can equip any extra function based on your requirement.
4. Q: Does your crane have safety devices?
A: Of course, we have all cut off limits and alarms for safety reasons.
5. Q: How can I install the crane to my vessel?
A: We can send our service engineers to the vessel site for guiding or ship the crane in whole pieces.
For more details, please feel free to contact us.
